The Mikoyan-Gurevich MiG-15 is a jet fighter aircraft developed by Mikoyan-Gurevich for the Soviet Union in the Begovoy District, Moscow, RSFSR. The MiG-15 was one of the first successful jet fighters to incorporate swept wings to achieve high transonic speeds. In aerial combat during the Korean War, it outclassed straight-winged jet day fighters, which were largely relegated to ground-attack roles.
The MiG-15 is believed to have been one of the most produced jet aircraft with more than 13,000 manufactured. The MiG-15 remains in service with the Korean People's Army Air Force as an advanced trainer. The USSR built 1344 MiG-15, 8352 MiG-15bis and 3434 two-seaters.
General characteristics Mig-15bis
Crew: 1
Length: 10.102 m (33 ft 2 in)
Wingspan: 10.085 m (33 ft 1 in)
Height: 3.7 m (12 ft 2 in)
Empty weight: 3,681 kg (8,115 lb)
Gross weight: 5,044 kg (11,120 lb)
Max takeoff weight: 6,106 kg (13,461 lb) with 2x600 L (160 US gal; 130 imp gal) drop-tanks
Fuel capacity: 1,420 L (380 US gal; 310 imp gal) internal
Powerplant: 1 × Klimov VK-1 centrifugal-flow turbojet, 26.5 kN (5,950 lbf) thrust
Performance
Maximum speed: 1,076 km/h (669 mph, 581 kn) at sea level
1,107 km/h (688 mph; 598 kn) / M0.9 at 3,000 m (9,843 ft)
Maximum speed: Mach 0.87 at sea level
Cruise speed: 850 km/h (530 mph, 460 kn) Mach 0.69
Ferry range: 2,520 km (1,570 mi, 1,360 nmi) at 12,000 m (39,370 ft) with 2x600 L (160 US gal; 130 imp gal) drop-tanks
Service ceiling: 15,500 m (50,900 ft)
Rate of climb: 51.2 m/s (10,080 ft/min)
Armament
Guns: **2 × 23 mm Nudelman-Rikhter NR-23 autocannon in the lower left fuselage (80 rounds per gun, 160 rounds total)
1 × 37 mm Nudelman N-37 autocannon in the lower right fuselage (40 rounds total)
Hardpoints: 2 , with provisions to carry combinations of:
Bombs: 100 kg (220 lb) bombs
Other: drop tanks, or unguided rockets
